AWAKE FRAME

ED ZUNDA SIGNATURE FRAME

Our most responsive Street frame yet, Ed Zunda’s signature AWAKE frame was designed with the technical street assassin in mind. Ed's first request was a 13" (slammed) rear end and a steeper 75.5 degree headtube and a 11.75" bottom bracket. We beefed up the backend with 6mm invest casted dropoutS, which use a special designed shape that gives ample clearance for pegs and hub guards, even with the rear wheel slammed all the way back.

Includes lifetime guarantee.



SPECIFICATIONS

TUBING:
butted, seamless 4130 chromoly tubing japanese

TOPTUBE:
20.85 "or 21.15" TT

CHAINSTAY LENGTH:
13.2" with 25-9 gearing, 13" slammed

ANGLES:
HT: 75.5 °, ST: 70.5 °

BOTTOM BRACKET:
mid-bb width: 74mm, height: 11.75 ", cnc machined and heat-treated

HEADTUBE:
cnc machined and heat-treated, integ. h / set, drilled for included gyro tabs

DROPOUTS:
 6mm thick investment cast and heat-treated

SPECIAL FEATURES:

frame comes without repl. brake hardware

 extruded top tube with integrated threads for cable guides

CNC machined seat and chainstay bridges

 top and down tube gussets

dent resistant rear triangle allows clearance for a 2.4 " tire

COLORS:
matt black, translucent frost blue

WEIGHT:
est. 2.3kg / 5.2bs (21.15")



AS AGILE AS A BUTTERFLY AND AS STURDY AS AN OX, THE AWAKE FRAME IS THE ULTIMATE BLEND OF MODERN, RESPONSIVE GEOMETRY AND DEPENDABLE, TIME PROVEN FRAME BUILDING TECHNOLOGY.

INCLUDES LIFETIME GUARANTEE.


FRAME GEOMETRY

A: Top Tube :  20.85” or 21.15"

B: Chain Stay: 13.2" with 25-9

C: Head Tube Angle: 75.5°

D: Seat Tube Angle: 70.5°

E: Bottom Bracket Height: 11.75”

F: Stand Over Height: 8.75"
