AVENGER



AVENGER 27.5" COMPLETE BIKE

A mix of the old and the new, our 27.5” clunker is something unique to say the least. Taking our BMX heritage and combining it with new school MTB technology, the AVENGER is perfect for smashing it down the single track on the weekend or just getting form A to B in style.


GALLERY

COLORWAY: PHOSPHATE RAW

CLICK IMAGE FOR FULL SIZE GALLERY


SPECIFICATIONS

Frame: WETHEPEOPLE "AVENGER" frame, 4130 full crmo

Fork: WETHEPEOPLE "AVENGER" fork, 4130 full crmo, 33mm offset

Bars: WETHEPEOPLE "AVENGER" bar, 4130 full crmo

Grips: SALT “CLAMP ON” flangeless grips, 145mm

Stem: WETHEPEOPLE "AVENGER" cnc top load stem, 1-1/8", 49mm reach

Headset: FSA "ORBIT UF-NO.2N" headset

Gyro: -

Lever: SHIMANO "BL-MT200", disc brake lever

Brakes: SHIMANO "BL-MT200", hydraulic disc brake with 160 mm rotors

Cranks: SALT "AVENGER" tubular 3pc "TSS" crank crmo 175mm, 8 spline

BB:  SALTPLUS "BSA" (68mm), 19mm, external, sealed bearing

Pedals: WETHEPEOPLE "LOGIC" nylon/fiberglass pedals

Chain: WETHEPEOPLE "SUPPLY" chain, Z510HX type

Sprocket  WETHEPEOPLE "PATROL" 6061-T6 alloy, 42t cnc sprocket

Driver: 18t cog, cassette driver, sealed bearing

Front Hub: WETHEPEOPLE "AVENGER" disc front hub, fully sealed, M6 female bolts, 36h

Rear Hub: WETHEPEOPLE "AVENGER" disc cassette hub, fully sealed, 3/8" female bolts, 36h

Hubguards: -

Front Rim: WETHEPEOPLE "AVENGER-DB-32" 27.5" double wall, 36h

Rear Rim: WETHEPEOPLE "AVENGER-DB-32" 27.5" double wall, 36h

Seat: WETHEPEOPLE "AVENGER" railed seat

Seat Post: WETHEPEOPLE "AVENGER" 27.2mm, seat post, alloy

Seat Clamp: WETHEPEOPLE "AVENGER" 29.8mm forged alloy seat clamp

Tires: WTB "BREAKOUT" tires, 27.5"x 2.3" front & rear

Pegs: -

Weight: 14.88kg / 32.84lbs


FRAME GEOMETRY

A: Top Tube Length:  24.5”

B: Chain Stay Length: 18.75”

C: Head Tube Angle: 70°

D: Seat Tube Angle: 68°

E: Bottom Bracket Height: -63mm

F: Stand Over Height: -


BAR GEOMETRY

G: Bar Rise: 4.3“

H: Bar Width: 31.1”

I: Bar Back Sweep: 14°

J: Bar Up Sweep:
