ENVY CARBONIC

Heading

ENVY CARBONIC

We took what was already the highest specc’d complete BMX bike in the game and gave it a nitrous boost. The ENVY CARBONIC takes the legendary WETHEPEOPLE ENVY and gives it one of the most progressive and game changing technical upgrades ever seen on a complete. Now rolling on the ECLAT CARBONIC carbon fibre rims and with a slick stealth black makeover, the ENVY CARBONIC begins the dawn of a new era in BMX design. Fully laden with only the very best parts from ECLAT including the ECLAT Storm XLT fork, Mirage Tires and ground-breaking Seismic hubs, the ENVY CARBONIC sacrifices no investment. A bike which is set to turn heads and spark intrigue wherever it goes, you’re going to have a hard time deciding if you want to put it in a display case or push it to the absolute limit. AVAILABLE IN 20.5” OR 21” TOPTUBES IN RSD AND LSD. INCLUDES LIFETIME GUARANTEE ON THE FRAME & FORK

arrow-left

ENVY CARBONIC

ENVY CARBONIC

ENVY CARBONIC

ENVY CARBONIC

SPECIFICATIONS
plus
FRAME:
WETHEPEOPLE "ENVY XLT", 4130 full crmo, hydroformed gussets, lasercut 6.0mm dropouts, 120mm head tube
FORK:
ÉCLAT "STORM XLT" fork, post liquid heat-treated & butted sanko tubing, 24mm offset
BARS:
WETHEPEOPLE "ENVY XLT" bar, 4130 full butted sanko, post liquid heat-treated, 25.4mm clamping
Grips:
ÉCLAT "SHOGUN" grips, flangeless, with ÉCLAT "TECH-BOLT" barends
STEM:
ÉCLAT "DUNE" topload stem, cnc alloy, 50mm reach, 25.4mm clamping
HEADSET:
WETHEPEOPLE "COMPACT" int. headset, sealed bearing
GYRO:
holes for removable gyro tabs
LEVER:
ÉCLAT "SNIPER" hinged brake lever, alloy, two finger version
BRAKES:
ÉCLAT "TALON" u-brake rear, alloy, with carbon safe extra soft brakepads
CRANKS
ÉCLAT "TIBIA" tubular 2.5pc crank, 22mm, crmo, 170mm, 48 spline
BB:
ÉCLAT "CNC" bb, 22mm, press fit, sealed bearing
PEDALS:
ÉCLAT "CONTRA" pedals, nylon/fiberglass
CHAIN:
WETHEPEOPLE "DEMAND" chain, K1 type
SPROCKET:
ÉCLAT "ABYSS" sprocket, cnc, 6061-T6 alloy, 25t
DRIVER:
1pc cassette driver, 9t, sealed bearing, TCS System
FRONT HUB:
ÉCLAT "SEISMIC" hub, fully sealed, 3/8"s female bolts, 36h
REAR HUB:
ÉCLAT "SEISMIC" cassette hub, fully sealed, 9t, 14mm axle, 36h, TCS driver (available in RSD or LSD)
HUBGUARDS:
ÉCLAT hub guards - nylon/fiberglass front (x2), nylon/fiberglass rear (x2)
FRONT RIM:
ÉCLAT "CARBONIC" rim, "Toryca" carbon fibre, 37mm wide, tubeless ready, 36h
REAR RIM:
ÉCLAT "CARBONIC" rim, "Toryca" carbon fibre, 37mm wide, tubeless ready, brake compatible, 36h
SEAT:
ÉCLAT "BIOS" pivotal seat, fat padded
SEAT POST:
ÉCLAT "TORCH" pivotal seat post , 230mm, alloy
SEAT CLAMP:
integrated seat clamp
TIRES:
ÉCLAT "MIRAGE" tires - 2.45" front & rear
PEGS:
-
WEIGHT:
10.81kg / 23.8lbs
COLORS:
matt black
/
-
/
-
GEOMETRY
plus

FRAME
A - TOP TUBE LENGTH:
20.5" | 21"
B - CHAIN STAY LENGTH:
12.5" (12.5"-13.35")
C - HEAD TUBE ANGLE:
75.25°
D - SEAT TUBE ANGLE:
71.5°
E - BB HEIGHT:
11.7"
F - STANDOVER HEIGHT:
8.75"

HANDLE BAR
G - BAR RISE:
9.4"
H - BAR WIDTH:
29.8"
I - BAR BACK SWEEP:
10.5°
J - BAR UP SWEEP:
FEATURES
plus
No items found.
