TRUST FC



TRUST FC COMPLETE BIKE

The Trust is a bike with such a strong following that offering it in a full street upgrade version was a natural progression. Taking the same incredible setup but injetcing Battleship inspired geometry like the 12.75” chainstay and adding a SALTPLUS Vertex freecoaster hub, x4 nylon hubguards and a full crmo 4pc bar, the Trust FC is everything you could need in a street bike.

Boasting a 20.75’ toptube and an aftermarket level frame, the Trust features a full ECLAT aftermarket parts injection featuring the super wide Trippin rim and Decoder tires. We couldn’t be more excited to offer this incredible bike to riders looking to push their riding to the next level out on the streets.


GALLERY

COLORWAY: MATT BLACK

CLICK IMAGE FOR FULL SIZE GALLERY

COLORWAY: TRANSLUCENT BERRY PINK

CLICK IMAGE FOR FULL SIZE GALLERY


SPECIFICATIONS

Frame: 4130 full crmo, tapered SS & CS, removable pivots & guides, 127mm head tube

Fork: SALTPLUS “TRUST” fork, full 4130 crmo , butted crmo steerer 22mm offset

Bars: SALTPLUS "HQ" 4pc full 4130 crmo bar

Grips: ÉCLAT “SHOGUN” flangeless grips, ÉCLAT “TECK-BOLT” barends

Stem: ÉCLAT “ONYX” cold-forged alloy top loading stem, 50mm reach

Headset: SALT “PRO” int. headset, sealed bearing

Gyro: no / holes for removable gyro tabs

Lever: SALT “MOTO” alloy brake lever

Brakes: ÉCLAT "TALON" alloy u-brake-rear

Cranks: SALTPLUS “ELITE” (L&R) tubular 3pc crank crmo 170mm, 48 spline

BB: SALT “MID” 19mm, press fit, sealed bearing

Pedals:  WETHEPEOPLE “Logic” nylon/fiberglass pedals

Chain: WETHEPEOPLE “SUPPLY” chain, Z510HX type

Sprocket ÉCLAT “ONYX” cold-forged alloy, 25t sprocket

Driver: 9t, 1pc freecoaster driver, sealed bearing

Front Hub: SALTPLUS “TRAPEZ” hub, sealed beraing, 3/8”s female bolts, 36h

Rear Hub: SALTPLUS “VERTEX" freecoaster hub, full sealed, 9t, 14mm axle, 36h, RSD

Hubguards: SALTPLUS "PRO" Nylon/Fibreglass hubguards (x4)

Front Rim: ÉCLAT “TRIPPIN” 38mm double wall rim, 36h

Rear Rim: ÉCLAT “TRIPPIN” 38mm double wall rim, 36h

Seat: ÉCLAT “BIOS” fat padded pivotal seat

Seat Post: SALT “AM” pivotal seat post, alloy, 150mm

Seat Clamp: WETHEPEOPLE “LOGIC” seat clamp 4130 crmo

Tires: ÉCLAT “DECODER” tire, 2.40” front & rear

Pegs: SALT "AM" nylon pegs, 4.5" long, x2

Weight:  12.51kg / 27.58lbs - with pegs, without brakes


FRAME GEOMETRY

A: Top Tube Length:  20.75"

B: Chain Stay Length: 12.75”

C: Head Tube Angle: 75.5°

D: Seat Tube Angle: 71°

E: Bottom Bracket Height: 11.7”

F: Stand Over Height: 9”


BAR GEOMETRY

G: Bar Rise: 9.4“

H: Bar Width: 29.6”

I: Bar Back Sweep: 11°

J: Bar Up Sweep:
